IPC-T249HA-LU 2.8mm HiLook 4MP Hybrid ColorVu IP Network Turret Camera with built-in Mic, 30m IR & White Light
- INFO
- SPECS
- DOWNLOADS
- RELATED
- VIDEOS
HiLook by Hikvision IPC-T249HA-LU 4MP Hybrid ColorVu IP Network Turret Camera
IPC-T249HA-LU is a sophisticated 4MP Hybrid ColorVu IP network turret camera featuring 2560 x 1440 high definition resolution, built-in microphone, 2.8mm fixed lens and up to 30m dual IR & white light LED illumination.
This camera features the latest Hybrid ColorVu technology with Smart Motion Detection to target human and vehicle objects. Hybrid ColorVu technology allows the camera to operate at night in different modes for optimal performance, working in IR mode for optimum distance viewing or ColorVu mode for full colour maximum detail, or Smart Mode where the camera default night mode is IR but switches to ColorVu mode on motion detection.ColorVu technology provides 24/7 vivid colourful images at night through the use of high performance ultra low light sensor and large aperture lens to vastly improve the utilization of available light. In zero-light scenarios, built-in, warm supplemental LEDs works to guarantee colourful images.
Smart Motion 2.0 utilises Hikvision's latest deep learning algorithms to identify and filter human or vehicle targets from other moving objects.
This camera supports built-in microphone for audio recording, plug and play PoE (Power of Ethernet) connections for easy installation and uses the latest H.265 / H.265+ compression saving considerable bandwidth and data storage requirements. Motion detection, privacy masking, video tampering, day/night switch and image settings supported.
The camera is manufactured in metal and plastic construction and IP67 weather resistant housing making it suitable for both indoor and outdoor applications with 3 axis adjustment allowing horizontal & vertical mounting options.
Key Features
- 4 Megapixel high-performance
- 24/7 ColorVu technology
- 2.8mm fixed lens
- Built in Microphone
- Supports H.265 / H.265+ compression
- Up to 30m dual IR and white light distance
- Water and dust resistant (IP67)
- Mobile monitoring via Hik-connect
How smart hybrid light works
Mode 1: IR Only: Night Image Black and White
Mode 2: White LED only: Night Image Full Colour
Mode 3: Dual mode as below:
When there is no vehicle or person, the camera uses only the IR light. When a vehicle or person appears, the white light is automatically triggered, resulting in vivid color imaging with clear details When the vehicle or person leaves, the camera switches back to the IR light. - Camera
- Image Sensor1/3" Progressive Scan CMOS
- Max. Resolution2560 × 1440
- Min. IlluminationColor: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
- Shutter Time1/3 s to 1/100,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
- Lens
- Lens TypeFixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 96°, vertical FOV 52°, diagonal FOV 114°
4 mm, horizontal FOV 80°, vertical FOV 43°, diagonal FOV 93°
- Lens MountM12
- Iris TypeFixed
- ApertureF1.0
- DORI
- DORI
2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
- Illuminator
- Supplement Light TypeIR,White Light
- Supplement Light RangeUp to 30 m
- Smart Supplement LightYes
- IR Wavelength850 nm
- Video
- Main Stream
50 Hz:
20 fps (2560 × 1440)
25 fps (1920 × 1080, 1280 × 720)
60 Hz:
20 fps (2560 × 1440)
24 fps (1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Bit Rate ControlCBR,VBR
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Region of Interest (ROI)1 fixed region for main stream
- Audio
- Audio TypeMono sound
- Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate8 kHz/16 kHz
- Environment Noise FilteringYes
- Network
- ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP
- Simultaneous Live ViewUp to 6 channels
- APIOpen Network Video Interface (Profile S, Profile T),ISAPI,SDK
- SecurityPassword protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- ClientiVMS-4200,HiLookVision
- Web Browser
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image
- Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Day/Night SwitchDay,Night,Auto,Schedule
- Wide Dynamic Range (WDR)120 dB
- SNR≥ 52 dB
- Image EnhancementBLC,HLC,3D DNR
- Privacy Mask4 programmable polygon privacy masks
- Interface
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- Built-in MicrophoneYes
- Event
- Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
- LinkageUpload to FTP,notify surveillance center,send email,trigger capture
- General
- Power
12 VDC ± 25%, 0.5 A, max. 6.0 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 7.5 W
- MaterialMetal & Plastic
- DimensionØ112 mm × 82 mm (Ø4.41" × 3.23")
- Package Dimension150 mm × 150 mm × 141 mm (5.91" × 5.91" × 5.55")
- WeightApprox. 375 g (0.8 lb.)
- With Package WeightApprox. 610 g (1.3 lb.)
- Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- LanguageEnglish, Ukrainian
- General FunctionHeartbeat, anti-banding, mirror, password protection,password reset by email
- Approval
- EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- ProtectionIP67: IEC 60529-2013
