CCTV Global DM80IPS03F40W 4K 8MP IP Network Turret Camera
DM80IPS03F40W is a 4K 8MP IP network dome camera featuring 3840 × 2160 resolution. This camera uses the superior Sony IMX415 Starvis sensor for high quality low light output, a 3.6mm fixed lens and up to 40m smart IR illumination. This camera supports 12V DC or PoE (Power of Ethernet) connections for easy installation and uses the latest H.265 / H.265+ compression saving considerable bandwidth and data storage requirements.
The camera is manufactured in all metal construction IP67 weather resistant housing making it suitable for both indoor and outdoor applications with 3 axis adjustment allowing horizontal & vertical mounting options.
The camera supports ONVIF allowing it to be connected to Hikvision, Dahua, Uniview and other NVR brands supporting the ONVIF protocol. In addition the camera includes Micro SD slot for additional Micro SD storage card (sold separately) to allow the camera to work as standalone (requires mobile or desktop app for playback). This camera supports snapshot upload via Cloud (for dropbox or Google) plus FTP and SMTP.
Key Features
- 1/2.8" Ultra Low light SONY IMX415 Starvis Sensor
- 3840x2160@20FPS, 2592x1944@25FPS, 2560x1440@25FPS, 1920x1080@25FPS
- POE (802.3af) or 12VDC
- ONVIF 2.4
- Hikvision Protocol, ONVIF Protocol
- Micro SD storage slot (up to 128Gb)
- Snapshot to cloud storage supported
- WDR, 3D DNR, Defog
- 3.6mm Fixed Lens
- IP67 Weatherproof
- Up to 40m IR night vision
- Support IE Explorer or Mac Safari
- Support P2P easy remote viewing for Mobile
Sample Image Daytime
Sample Image Night time (results will vary depending on ambient lighting)
Camera Image Sensor Sony Starvis IMX415 Main processor Hi3516AV3 Resolution 8MP Effective Pixels 3840(H)*2160(V) Compression H.264/H.265/JPEG/AVI /MJPEG TV System PAL/NTSC Electronic Shutter Time Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec S/N Ratio ≥52dB Scanning System Progressive Video Output Network Lens Focus Length 3.6mm (approx 93° Horizontal FOV) Focus Control NA Lens Type Fixed Board Pixels 8M Night Vision Infrared LED 42µ x 2PCS Infrared Distance 40m max IR Status Auto Control IR Power On Auto Control Network Ethernet RJ-45 (10/100Base-T) Protocol TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP ONVIF Support ONVIF 2.4 P2P YES, Support QR Code POE Optional/Internal, Support IEEE 802.3af Video Delay 0.3S (Within the Lan) Main Stream 1 3840*2160@20fps Main Stream 2 2592*1944@25fps / 2560*1440@@25fps Main Stream 3 1920*1080@25fps Sub Stream 1 720*480@25fps Tri Stream 352*288@25fps IE Brower IE8-11, Chrome, Mac Safari Smart Phone iPhone, iPad, Android, Android Pad Camera Features Day/Night Color/ B&W (IR-CUT ) Image Config Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control), Video Tampering Corridor Pattern Support Defog Mode Support BLC Support WDR Support 96dB Motion Detection Support Privacy Masking 3 Rectangular Zone Recording Mode NVR/CMS/Web Language Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands Interface SD Card Slot NA General Housing IP67 IR Cut Filter YES Operation Temperature -20℃ ~ +60℃ RH95% Max Storage Temperature -20℃ ~ +60℃ RH95% Max Power Source DC12V±10%,800mA or POE 802.3af Dimension ￠109 x 93(H) mm Weight 800g
